Thermaltake CTE T500 Air Snow E-ATX Full Tower Cabinet White

Description

P/N	CA-1X8-00F6WN-00
SERIES	CTE
CASE TYPE	Full Tower
DIMENSION (H X W X D)	1. 615 x 275 x 516 mm 2. (24.21 x 10.83 x 20.31 inch)
NET WEIGHT	15.6 kg / 34.39 lbs.
PANEL	4mm Tempered Glass x 1
COLOR	White
MATERIAL	SPCC / ABS
COOLING SYSTEM	1. Front(intake): i. 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1 2. Top(exhaust): i. 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1 3. Rear(intake): i. 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 1
DRIVE BAYS	4 x 3.5” or 6 x 2.5”
EXPANSION SLOTS	7
MOTHERBOARDS	1. 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 2. 12” x 9.6” (ATX), 12” x 13” (E-ATX)
I/O PORT	USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1
PSU	Standard PS2 PSU (optional)
FAN SUPPORT	1. Front: i. 3 x 120mm, 2 x 120mm, 1 x 120mm ii. 3 x 140mm, 2 x 140mm, 1 x 140mm 2. Top: i. 2 x 120mm, 1 x 120mm ii. 2 x 140mm, 1 x 140mm 3. Right: i. 1 x 120mm, 1 x 140mm 4. Rear: i. 3 x 120mm, 2 x 120mm, 1 x 120mm ii. 3 x 140mm, 2 x 140mm, 1 x 140mm 5. Bottom: i. 1 x 120mm, 1 x 140mm 6. PSU Cover: 1 x 120mm, 1 x 140mm
RADIATOR SUPPORT	1. Front: i. 1 x 360mm, 1 x 240mm, 1 x 120mm ii. 1 x 420mm(AIO only), 1 x 280mm, 1 x 140mm 2. Top: i. 1 x 120mm(AIO only) 3. Rear: i. 1 x 360mm, 1 x 240mm, 1 x 120mm ii. 1 x 280mm, 1 x 140mm
CLEARANCE	1. CPU cooler max height: 195mm 2. VGA max length: 385mmPSU 3. max length: 180mm
