MSI B550M PRO-VDH Wifi Motherboard

Category: Uncategorized

Description

Additional information

CPU	1. Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series desktop processors
CHIPSET	1. AMD B550 Chipset
MEMORY	1. 4x DDR4 memory slots, support up to 128GB a. Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC b. Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE i. 1DPC 1R max speed 4400 MHZ ii. 1DPC 2R max speed 3733 MHZ iii. 2DPC 1R max speed 3866 MHZ iv. 2DPC 2R max speed 3466 MHZ 2. Dual channel memory architecture 3. Supports non-ECC UDIMM memory 4. Supports ECC UDIMM memory 5. Supports un-buffered memory
EXPANSION SLOT	1. 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1) 2. 2x PCIe 3.0 x1 slots
ONBOARD GRAPHICS	1. 1x VGA port, supports resolution of 2048×1536 @50Hz, 2048×1280 @60Hz, 1920×1200 @60Hz 2. 1x DisplayPort, supports a maximum resolution of 4096×2160 @60Hz 3. 1x HDMI™ 2.1 port, supports a maximum resolution of 4096×2160 @60Hz Support HDCP 1.4 & 2.3 4. Maximum shared memory of 16 GB Note:- a. Available for the processor with integrated graphics. b. Graphics specifications may vary depending on the CPU installed.
STORAGE	1. AMD B550 Chipset 2. 4x SATA 6Gb/s ports 3. 2x M.2 slots (Key M) a. M2_1 slot (from AMD Processor) i. Supports PCIe 4.0/ 3.0 x4 ii. Supports SATA 6Gb/s iii. Supports 2242/ 2260/ 2280 storage devices b. M2_2 slot (from AMD B550 chipset) i. Supports PCIe 3.0×4 ii. Supports 2242/ 2260/ 2280 storage devices Note:- a. The supported specification depends on installed processor.
RAID	1. Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices 2. Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
USB	1. AMD B550 Chipset a. 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector) b. 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) 2. AMD Processor a. 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
AUDIO	1. Realtek® ALC892/ALC897 Codec a. 7.1-Channel High Definition Audio
LAN	1. 1x Realtek® 8111HN Gigabit LAN controller
INTERNAL I/O CONNECTORS	1. 1x 24-pin ATX main power connector 2. 1x 8-pin ATX 12V power connector 3. 4x SATA 6Gb/s connectors 4. 2x M.2 slots (M-Key) 5. 1x USB 3.2 Gen 1 5Gbps Type-C port 6. 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 7. 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 8. 1x 4-pin CPU fan connector 9. 1x 4-pin water-pump fan connector 10. 3x 4-pin system fan connectors 11. 1x Front panel audio connector 12. 2x System panel connectors 13. 1x Serial port connector 14. 1x Chassis Intrusion connector 15. 2x 4-pin RGB LED connectors 16. 2x 3-pin RAINBOW LED connectors 17. 1xTPM module connector 18. 1x Clear CMOS jumper
BACK PANEL PORTS	1. VGA 2. USB 3.2 Gen 1 5Gbps Type-A 3. Keyboard / Mouse 4. LAN 5. Flash BIOS Button 6. DisplayPort 7. HDMI™ 8. USB 2.0 9. USB 3.2 Gen 1 5Gbps Type-A 10. Wi-Fi Antenna connectors 11. 3x Audio jacks
FORM FACTOR	Micro-ATX Form Factor; 24.4 cm x 24.4 cm
