MSI B450M-A PRO MAX Motherboard

Category: Uncategorized

Description

Additional information

CPU	1. Supports 1st, 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics / Athlon™ with Radeon™ Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4
CHIPSET	1. AMD® B450 Chipset
MEMORY	1. 2 x DDR4 memory slots, support up to 64GB *ComboPI 1.0.0.3-based and above BIOS are required. 2. Support DDR4 1866/ 2133/ 2400/ 2667Mhz(by JEDEC) a. For AMD Ryzen Gen3 (R5/R7/R9) i. 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) b. For AMD Other CPU i. 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE) 3. Dual channel memory architecture 4. Supports ECC UDIMM memory (non-ECC mode) 5. Support non-ECC UDIMM memory
EXPANSION SLOTS	1. 1 x PCIe 3.0 x16 slot a. Supports x16 speed i. 1st, 2nd and 3rd Gen AMD Ryzen™ b. Supports x8 speed i. Ryzen™ with Radeon™ Vega Graphics ii. 2nd Gen AMD Ryzen™ with Radeon™ Graphics iii. A-series iv. Athlon™ X4 c. Supports x4 speed i. AMD® Athlon™ with Radeon™ Vega Graphics 2. PCIe 2.0 x1 slot
ONBOARD GRAPHICS	1. 1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz12 2. 1 x HDMI™ 2.0b with HDR port, supports a maximum resolution of 4K @60Hz123 Note:- a. Only support when using the processor with Graphicss b.Maximum shared memory of 2048 MB c.Graphics specifications may vary depending on the CPU installed.
STORAGE	1. AMD® B450 Chipset 2. 4 x SATA 6Gb/s ports a. Supports RAID 0, RAID1 and RAID 10 3. 1x M.2 slot (Key M) a. Supports PCIe 3.0 x4 and SATA 6Gb/s i. 1st, 2nd and 3rd Gen AMD Ryzen™ ii. Ryzen™ with Radeon™ Vega Graphics iii. 2nd Gen AMD Ryzen™ with Radeon™ Graphics b. Supports PCIe 3.0 x2 and SATA 6Gb/s i. AMD® Athlon™ with Radeon™ Vega Graphics ii. A-series iii. Athlon™ X4 c. Supports 2242/2280/22110 storage devices
USB	1. AMD® B450 Chipset a. 6x USB 3.2 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector) b. 6x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
AUDIO	1. Realtek® ALC892/ALC897 Codec a. 7.1-Channel High Definition Audio
LAN	1. 1 x Realtek® 8111H Gigabit LAN controller
INTERNAL I/O CONNECTORS	1. 1x 24-pin ATX main power connector 2. 1x 4-pin ATX 12V power connector 3. 4x SATA 6Gb/s connectors 4. 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 5. 1x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports) 6. 1x 4-pin CPU fan connector 7. 1x 4-pin system fan connector 8. 1x Front panel audio connector 9. 2x Front panel connectors 10. 1x TPM module connector 11. 1x Chassis Intrusion connector 12. 1x Serial port connector 13. 1x Clear CMOS jumper
BACK PANEL PORTS	1. Mouse 2. DVI-D Port 3. USB 3.2 Gen1 4. LAN Port 5. Keyboard 6. HDMI™ Port 7. USB 2.0 Ports 8. HD Audio Connectors
FORM FACTOR	M-ATX Form Factor; 23.6 cm x 20.0 cm
OPERATING SYSTEM	1. Support for Windows® 10 64-bit 2. Support for Windows® 7 64-bit Note:- a. To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
