| 3.5/2.5 UNIVERSAL DRIVE BRACKETS | 6 included, 14 positions total |
|---|---|
| DEDICATED 2.5 DRIVE BRACKETS | 2 trays included, 4 positions total |
| 5.25 DRIVE MOUNTS | 1 |
| EXPANSION SLOTS | 7 + 2 |
| FRONT PORTS | 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button |
| TOTAL FAN MOUNTS | 9 x 120/140 mm |
| FRONT FAN | 3 x 120/140 mm (2 x Dynamic X2 GP-14 included) |
| TOP FAN | 3 x 120/140 mm |
| REAR FAN | 1 x 120/140 mm (1 x Dynamic X2 GP-14 included) |
| BOTTOM FAN | 2 x 120/140 mm |
| DUST FILTERS | Top, 2 x front, full length bottom |
| FIXED VELCRO STRAPS | Yes |
| CABLE ROUTING GROMMETS | Yes |
| CAPTIVE THUMBSCREWS | HDD brackets, SSD brackets, PSU bracket |
| LEFT SIDE PANEL | Industrial sound-damped steel or Tempered Glass |
| RIGHT SIDE PANEL | Industrial sound-damped steel |
| MOTHERBOARD COMPATIBILITY | E-ATX (max 285 mm) / ATX / mATX / mITX |
| POWER SUPPLY TYPE | ATX |
| PSU MAX LENGHT | 250 mm (with HDD cage installed) |
| GPU MAX LENGHT | Storage layout: 290 mm – Open layout: 470 mm (445 mm w/ front fan) |
| CPU COOLER MAX HEIGHT | 185 mm |
| FRONT RADIATOR | Up to 360/280 mm |
| TOP RADIATOR | Up to 360/420 mm |
| REAR RADIATOR | 120 mm |
| BOTTOM RADAITOR | Up to 240/280 mm |
| CABLE ROUTING SPACE | 30 mm |
| VERTICAL GPU SUPPORT (WITH FLEX B-20 OR FLEX VRC-25) | 65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling |
| CASE DIMENSIONS (LxWxH) | 547 x 240 x 475 mm |
| CASE DIMENSIONS W/O FEET/PROTRUSIONS/SCREWS | 533 x 240 x 451 mm |
| PACKAGE DIMENSIONS (LxWxH) | 558 x 363 x 641 mm |
| NET WEIGHT | Solid Version: 13.49 kg, TG Version: 13.45 kg |
| PACKAGE WEIGHT | Solid Version: 15.98 kg TG Version: 15.94 kg |
| VOLUME | 57.7 liters |
| WARRANTY | 2 Years |
| PACKAGE CONTENTS | Package contents |
| DEFINE 7 BLACK SOLID | SKU: FD-C-DEF7A-01 EAN: 7340172702191 UPC: 843276102197 JAN: 4537694275842 |
| DEFINE 7 BLACK TG LIGHT TINT | SKU: FD-C-DEF7A-02 EAN: 7340172702207 UPC: 843276102203 JAN: 4537694275859 |
| DEFINE 7 BLACK TG DARK TINIT | SKU: FD-C-DEF7A-03 EAN: 7340172702214 UPC: 843276102210 JAN: 4537694275866 |
| DEFINE 7 BLACK/WHITE TG CLEAR TINT | SKU: FD-C-DEF7A-05 EAN: 7340172702238 UPC: 843276102234 JAN: 4537694275880 |
| DEFINE 7 WHITE SOLID | SKU: FD-C-DEF7A-09 EAN: 7340172702276 UPC: 843276102272 JAN: 4537694276184 |
| DEFINE 7 WHITE TG CLEAR TINT | SKU: FD-C-DEF7A-06 EAN: 7340172702245 UPC: 843276102241 JAN: 4537694275897 |
| DEIFNE 7 GRAY SOLID | SKU: FD-C-DEF7A-07 EAN: 7340172702252 UPC: 843276102258 JAN: 4537694275903 |
| DEFINE 7 GRAT TG LIGHT TINT | SKU:FD-C-DEF7A-08 EAN: 7340172702269 UPC: 843276102265 JAN: 4537694275910 |
