Description
Additional information
| COLOR | White, Black |
|---|---|
| MATERIALS – EXTERIOR | Steel, Plastic, Tempered Glass |
| MATERIALS – LEFT SIDE PANEL | Grey TG + Steel |
| DIMENSIONS (L x W x H) | 406 x 231 x 415mm (Incl. Protrusions), 380 x 231 x 381mm (excl. Protrusions) |
| VOLUME | 33.44L (excl. Protrusions) |
| MOTHERBOARD SUPPORT | ITX, Micro ATX, ATX, E-ATX (Width up to 296mm w/ SFX PSU, up to 273 w/ ATX PSU) |
| EXPANSION SLOTS | 7 |
| 3.5 DRIVE BAYS | 4 |
| 2.5 DRIVE BAYS | 3 |
| I/O PANEL – USB PORTS | 2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C |
| I/O PANEL – AUDIO IN/OUT | 1x 3.5mm Combo |
| PRE-INSTALLED FANS – REAR | QUBE 500 Flatpack: 1x 120mm (1800 RPM) SF Black PWM, QUBE 500 Flatpack White: 1x 120mm (1800 RPM) SF White PWM |
| FAN SUPPORT – FRONT | 1x 120/140mm (x2 if PSU is mounted in bottom) |
| FAN SUPPORT – TOP | 2x 120/140mm |
| FAN SUPPORT – REAR | 1x 120mm |
| FAN SUPPORT – BOTTOM | 2x 120/140mm |
| FAN SUPPORT – LEFT SIDE | 2x 120/140mm |
| RADIATOR SUPPORT – FRONT | 120mm, 140mm, (240/280mm w/ PSU in bottom) |
| RADIATOR SUPPORT – TOP | 120mm, 140mm, 240mm, 280mm, (280mm can be used within 53mm thickness) |
| RADIATOR SUPPORT – REAR | 120mm |
| RADIATOR SUPPORT – BOTTOM | 120mm, 140mm, 240mm, 280mm |
| RADIATOR SUPPORT – LEFT SIDE | 120mm, 140mm, 240mm, 280mm |
| CLEARANCE – CPU COOLER | 164mm-172mm (Remove the water cooling bracket) |
| CLEARANCE – PSU | 173mm to first GPU slot, 216 maximum space (w/o cable management space), 332mm space mounted in bottom (w/o cable management space) |
| CLEARANCE – GFX | 365mm |
| CABLE ROUTING – BEHIND MOTHERBOARD TRAY | 29-32mm |
| HANDLE | QUBE 500 Flatpack: Black x 1, QUBE 500 Flatpack White: Grey x 1 |
| GEM MINI | QUBE 500 Flatpack: Black x 1, QUBE 500 Flatpack White: Grey x 1 |
| DUST FILTERS | Front, Top, Bottom, Right side |
| POWER SUPPLY SUPPORT | SFX, SFX-L, ATX |
| WARRANTY | 2 years |
| SERIES | QUBE Series |
| SIZE | Mid Tower |
