Cooler Master HAF 500 E-ATX Cabinet White

Description

COLORS	Black, White
MATERIAL – OUTLOOK	Steel, Mesh, Plastic
MATERIAL – SIDE PANEL	Tempered Glass, Steel
DIMENSIONS (L x W x H)	516 x 224 x 510mm (incl. Protrusions)
MOTHERBOARD SUPPORT	ITX, Micro ATX, ATX, SSI CEB, E-ATX, (up to 12 x 14.1, may impact cable management and case features, remove cable cover and GPU fan bracket features)
EXPANSION SLOTS	7
5.25 DRIVE BAYS	N/A
2.5 / 3.5 DRIVE BAYS (COMBO)	2
2.5 DRIVE BAYS	2
I/O PANEL	2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button
ARGB CONTROLLER	ARGB Hub
PRE-INSTALLED FANS – FRONT	2x 200mm ARGB Fan
PRE-INSTALLED FANS – REAR	1x 120mm SickleFlow PWM ARGB
PRE-INSTALLED FANS – TOP ON HDD CAGE	1x 120mm SickleFlow PWM (GPU Fan)
FAN SUPPORT – TOP	3x 120mm, 2x 140mm, 2x 200mm
FAN SUPPORT – FRONT	3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness
FAN SUPPORT – REAR	1x 120mm
FAN SUPPORT – TOP ON HDD CAGE	1x 120mm
RADIATOR SUPPORT – TOP	120mm, 140mm, 240mm, 280mm, 360mm
RADIATOR SUPPORT – FRONT	120mm, 140mm, 200mm, 240mm, 280mm, 360mm
RADIATOR SUPPORT – REAR	120mm
CLEARANCE – CPU COOLER	167mm/6.5
CLEARANCE – PSU	180mm/7.1
CLEARANCE – GFX	410mm/16.1
CABLE ROUTING – BEHIND MOTHERBOARD TRAY	30mm
DUST FILTERS	Top, Bottom
POWER SUPPLY SUPPORT	Bottom Mount, ATX
WARRANTY	2 years
SERIES	HAF Series
SIZE	Mid Tower
