| Model Name |
ASUS ZenWiFi XD6 Series(XD6)
|
| Network Standard |
WiFi 6 (802.11ax) Backwards compatible with 802.11a/b/g/n/ac Wi-Fi
|
| Product Segment |
AX11000 ultimate AX performance
|
| AX technology |
Yes
|
| Data Rate |
2.4GHz AX: 4×4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps 5G-1Hz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps 5G-2Hz AX: 4×4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
|
| Antenna |
External antenna x 8
|
| Transmit/Receive |
2.4GHz 4×4 5GHz-1 4×4 5GHz-2 4×4
|
| Processor |
1.8GHz quad-core processor
|
| Memory |
256MB NAND flash and 1GB DDR3 SDRAM
|
| Boosts speed |
OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth
|
| Operating Frequency |
Tri-band Wi-Fi
|
| Ports |
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4, Multi-Gig Ethernet port 2.5G/1G x1 USB 3.1 Gen 1 x 2
|
| Button |
WPS Button, Reset Button, Power Button, Wireless on/off Button, Boost Key
|
| LED Indicator |
Power x 1 Wi-Fi x 2 WAN x 1 LAN x 1 USB x 2 WPS x 1 2.5G Port x 1
|
| Power Supply |
AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 3.42 A current
|
| Package content |
GT-AX11000 Extreme Gaming Router RJ-45 Cable Power Adapter Quick Start Guide Warranty Card
|
| AiMesh |
AiMesh Primary AiMesh router AiMesh node
|
| Router APP |
ASUS Router APP
|
| Game |
Game Boost/acceleration Game Radar WTFast ROG_First OpenNAT (Game Profile) Gaming port
|
| Alexa |
Support Alexa skill
|
| IFTTT |
Support IFTTT
|
| AiProtection |
AiProtection Pro Router Security Assessment Malicious site blocking Two-Way IPS Infected Device Prevention and Blocking
|
| Parental Control |
Parental Control Parental Control Customized Internet schedule Maximum Parental Control profile :16 Maximum Parental Control content filter rule :16
|
| Wireless |
IPv6 MU-MIMO WiFi Encryption : Open system, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise UTF-8 SSID Guest Network Maximum Guest Network rule : 2.4GHz x3, 5GHz-1 x3, 5GHz2 x3 Guest Network Connection time limit Guest Network Encryption : Open system, WPA/WPA2-Personal WPS Wi-Fi MAC address filter Maximum MAC filters : 64 Wireless scheduler Wi-Fi Radar Airtime fairness RADIUS Client Universal beamforming
|
| Traffic Control |
Adaptive QoS Bandwidth Monitor Bandwidth limiter Maximum Bandwidth limiter rule :32 Traditional QoS Maximum Traditional QoS rule :32 Traffic Monitor Real-time traffic monitor Wired Traffic Monitor Wireless Traffic Monitor Traffic Analyzer Traffic analysis period : Daily, Weekly, Monthly Website history
|
| WAN |
Explicit beamforming Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN WAN Aggregation 3G/4G LTE dongle Android tethering Port forwarding Maximum port forwarding rule :64 Port triggering Maximum port triggering rule :32 DMZ DDNS NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay Let's Encrypt
|
| LAN |
DHCP Server IGMP snooping IPTV LAN Link Aggregation Manually assign IP address Maximum manually assign IP address rule :64
|
| VPN |
VPN Client L2TP VPN Client OVPN VPN Client PPTP VPN Server IPSec VPN Server OVPN VPN Server PPTP VPN Fusion
|
| USB application |
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 Safely Remove disk AiCloud Download master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder privileges
|
| Administration |
Operating mode : Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge Operating system : ASUSWRT Free OS upgrade Firewall Maximum Firewall keyword filter : 32 Maximum Firewall network service filter : 32 Maximum Firewall URL filter : 64 Wake on LAN (WOL) SSH Configuration backup and restore Diagnosis tools Feedback system System log
|
